Specifications

DIMENSIONS

Overall length	4,915 mm
Overall width	1,720 mm
Overall width of superstructure	1,548 mm
Overall height above cab	2,515 mm
Rear length	860 mm
Track width	1,420 mm
Landing gear length	2,155 mm
Landing gear width (dozer blade)	1,720 mm
Blade height	350 mm
Track link width	300 mm
Min. ground clearance	295 mm
Tail swing radius	886 mm
Distance between track wheel and guide wheel (centre)	1,670 mm
Boom length	2,540 mm
Arm length	1,400 mm
Bucket capacity	0.12 cubic meters

WORKING RANGE

Max. ground level range	5,465 mm
Max. excavation depth	3,105 mm
Max. vertical range	4,855 mm
Max. dumping height	3,460 mm
Minute radius of gyration	2,420 mm
Max. excavation depth, vertical wall	2,700 mm
Min. working machine height. Radius of gyration	3,690 mm

WEIGHT

Operating weight

3,790 kg (Plus 200kg bolt on counterweight)

ENGINE

Model	3TNV88F
Rated power	18.2 kW
Max. torque	94.2 Nm/1,320 rpm
Shift	1,642 l
Batteries	1 x 12 V / 80Ah

HYDRAULIC SYSTEM

Main pump	1 Adjustable axial piston pump
Max. oil flow	1 x 70 l/min
Travel drive	2 Adjustable axial piston pump
Rotary gear	1 Adjustable axial piston pump

RELIEF VALVE SETTING

Boom circuit	245 bar
Slewing circuit	206 bar
Drive circuit	245 bar
Pilot control circuit	35 bar

PERFORMANCE

Swing speed	10 rpm
Max. ground speed	4.4 km/h faster, 2.2 km/h slower
Max. travel force	36.8 kN
Climbing ability	30°
ISO bucket separation force	30.4 kN
ISO arm tear	18.2 kN

SERVICE REFILL CAPACITIES

Tank	40 l
Engine coolant	6.7 l
Engine oil	6.7 l
Travel drive (each side)	0.7 l
Hydraulic system	55 l
Hydraulic tank	40 l
