Specifications

Engine

Engine Displacement	148.5 cu in (2.4 L)
Engine Displacement	148.5 cu in (2.4 L)
Horsepower @ 2,700 rpm	65.2 hp (48.6 kW)
Maximum Torque @ 1,500 rpm	144.3 ft-lb (195.6 Nm)

Operating Performance

Operating Weight - Canopy	7,485 lb (3,395 kg)
Operating Weight - Cab	7,780 lb (3,530 kg)
Tipping Load	5,269 lb (2,390 kg)
Rated Operating Capacity, SAE J818*	1,841 lb (835 kg)
Operating Capacity w/ Opt Counterweight	2,041 lb (925 kg)
Operating Load at 50% of Tipping Load	2,635 lb (1,195 kg)
Bucket Breakout Force	5,930 lb (2,690 kg)
Lift Arm Breakout Force	4,860 lb (2,205 kg)
Traction Force	8,655 lb (3,926 kg)
Ground Pressure - 12.6" Track	5.1 psi (34.8 kPa)
Travel Speed - Low	4.3 mph (7.0 km/hr)
Travel Speed - High	6.2 mph (10.0 km/hr)

Hydraulic System

Auxiliary Flow - Primary Circuit	17.8 gpm (67.4 Lpm)
Hydraulic System Pressure	2,988 psi (20.6 MPa)

Fluid Capacities

Engine Lubrication	7.6 qt (7.2 L)
Cooling System	14.0 qt (13.0 L)
Fuel Tank Capacity	20.0 gal (75.7 L)
Fuel Consumption (65% of Full Load)	2.69 gal/hr (10.2 L /hr)
Hydraulic Reservoir Capacity	7.9 gal (30.0 L)
Hydraulic System Capacity	13.5 gal (51.0 L)

Dimensions

Max. Lift Height to Bucket Pin	9 ft 6.4 in (2,905 mm)
Dump Height Fully Raised	7 ft 5.6 in (2,275 mm)
Dump Reach Fully Raised	1 ft 10.0 in (560 mm)
Dump Angle	38°
Rollback Angle	31°
Track Ground Contact Length	4 ft 6.9 in (1,395 mm)
Machine Length	8 ft 9.9 in (2,689 mm)
Transport Length	10 ft 11.1 in (3,330 mm)
Transport Height	6 ft 5.8 in (1,975 mm)
Departure Angle	30°
Clearance Circle with Bucket	6 ft 10.5 in (2,095 mm)
Clearance Circle without Bucket	4 ft 6.9 in (1,395 mm)
Clearance Circle Rear	4 ft 11.8 in (1,520 mm)
Track Width	12.6 in (320 mm)
Ground Clearance	9.1 in (230 mm)
Overall Width without Bucket	5 ft 0.2 in (1,530 mm)
