Specifications

DIMENSIONS

Overall length	3,665 mm
Overall width	980/1,350 mm
Overall width of superstructure	980 mm
Overall height above cab	2,410 mm
Rear length	920 mm
Track width	750/1,120 mm
Landing gear length	1,585 mm
Landing gear width (dozer blade)	980/1,350 mm
Blade height	270 mm
Track link width	230 mm
Tail swing radius	920 mm
Distance between track wheel and guide wheel (center)	1,220 mm
Boom length	1,810 mm
Arm length	1,130 mm
Bucket capacity	0.04 cubic meters

WORKING RANGE

Max. ground level range	4,000 mm
Max. excavation depth	2,360 mm
Max. vertical range	3,665 mm
Max. dumping height	2,635 mm
Minute radius of gyration	1,705 mm
Max. excavation depth, vertical wall	2,215 mm
Min. working machine height. radius of gyration	2,745 mm

WEIGHT

Operating weight

1,865 kg

ENGINE

Model	Yanmar 3TNV80F
Rated power	14,6 kW
Max. torque	65,3 Nm/1,800 rpm
Shift	1267 cubic cm

HYDRAULIC SYSTEM

Main pump	1 Adjustable axial piston pump
Maximum oil flow	40 l/min
Travel drive	2 Adjustable axial piston pump
Rotary gear	1 Adjustable axial piston pump

RELIEF VALVE SETTING

Boom circuit	270 bar
Slewing circuit	162 Bar
Drive circuit	270 bar
Pilot control circuit	35 bar

PERFORMANCE

Swing speed	10 rpm
Max. ground speed	4 km/h faster, 2.7 km/h slower
Max. traction	15.6kN
Climbing ability	30°
ISO bucket separation force	15.2 kN
ISO arm tear	9.2kN

SERVICE REFILL CAPACITIES

Tank	20 l
Engine coolant	5.0 l
Engine oil	3.4 l
Travel drive (each side)	0.33 l
Hydraulic tank	21 l

Certain features may require an additional add-on package that may not be included in the retail or sale price. Please contact the dealership for full details.
